E5071C

The E5071C network analyzer offers the highest RF performance and fastest speed in its class, with a wide frequency range and versatile functions. The E5071C is the ideal solution for manufacturing and R&D engineers evaluating RF components and circuits for frequency range up to 20 GHz.

Detail

Specifications



  • Maximum Frequency                                       20 GHz
  • Dynamic Range                                                123 dB
  • Output Power                                                   10 dBm
  • Number of Built-In Ports                                  2 or 4 ports
  • Harmonics                                                        -25 dBc
  • Best Speed at 201 Point, 1 Sweep                    5 ms
  • Components                                                      Cables, Mixers/Frequency Converters, Amplifiers, Resonators
  • ​Benchtop                                                           Yes
  • Operating System                                             Windows XP / Windows 7 / Windows 10

Key Features and Specifications



  • 9 kHz to 4.5/6.5/8.5/14/20 GHz
  • 2- or 4-port, 50 ohm, S-parameter test set
  • Improve accuracy, yield and margins with wide dynamic range 130 dB, fast measurement speed 8 ms and excellent temperature stability 0.005 dB/°C
  • Obtain design confidence through complete characterization of high-speed serial interconnects with enhanced time domain analysis option
  • Protect your investment with upgradability across all of the options
